ABB Power Electronics System: GVC736CE101, 3BHE039203R0101 & 5SXE12-0184 Product Description

Name: ABB Power Electronics System: GVC736CE101, 3BHE039203R0101 &amp; 5SXE12-0184 Product Description
SKU: 1060
Availability: InStock

Product Overview

The ABB GVC736CE101, ABB 3BHE039203R0101, and ABB 5SXE12-0184 form a sophisticated power management ecosystem, engineered to deliver high performance and reliability in industrial automation systems. The ABB GVC736CE101 is a robust power converter module from ABB’s GVC series, designed for medium-voltage applications requiring efficient energy conversion and stable output. Complementing it, the ABB 3BHE039203R0101 serves as a high-precision control and monitoring board, specifically tailored to coordinate the operation of power modules like the GVC736CE101.

Rounding out the trio, the ABB 5SXE12-0184 is a high-power IGBT module from the 5SXE series, optimized for rapid switching and thermal efficiency. Together, these components create a synergistic solution: the 5SXE12-0184 handles high-current power conversion, the GVC736CE101 regulates voltage and power flow, and the 3BHE039203R0101 ensures real-time control and diagnostics. This integration enhances system stability, reduces energy losses, and extends operational lifespans, making them critical for industries where power reliability drives productivity.

Technical Specifications

Parameter Name	Parameter Value for GVC736CE101	Parameter Value for 3BHE039203R0101	Parameter Value for 5SXE12-0184
Product Model	GVC736CE101	3BHE039203R0101	5SXE12-0184
Manufacturer	ABB	ABB	ABB
Product Type	Medium-Voltage Power Converter Module	Control & Monitoring Board	High-Power IGBT Module
Rated Voltage	3.3kV (Input) / 400V (Output)	24V DC (Control Voltage)	1700V
Rated Current	75A (Continuous Output)	6A (Max Control Current)	400A (Collector Current)
Operating Temperature	-10°C to +55°C	-20°C to +70°C	-40°C to +125°C
Dimensions	280mm x 220mm x 150mm	190mm x 140mm x 30mm	160mm x 115mm x 35mm
Mounting Type	Panel Mount with Locking Brackets	DIN Rail Mount (35mm Standard)	Heat Sink Mount (M8 Screws)
Protection Features	Overvoltage, Overcurrent, Earth Fault	Short Circuit Protection, ESD Immunity	Overcurrent, Overtemperature, Voltage Clamp
Communication Protocols	Profibus DP, Ethernet IP	Modbus RTU, Ethernet/IP	N/A
Compliance	IEC 61800-5-1, CE Certified	IEC 61131-2, RoHS 2	IEC 60747-12, RoHS 2

Main Features and Advantages

Efficient power conversion: The ABB GVC736CE101 excels in medium-voltage applications with its advanced converter topology, achieving up to 97.5% efficiency in power conversion—critical for reducing energy waste in industrial drives and renewable energy systems. Its modular design allows for easy scaling, supporting parallel configurations to meet higher power demands.

Precision control: The ABB 3BHE039203R0101 delivers real-time monitoring and adaptive control with a response time of less than 5µs, ensuring optimal performance of connected power modules like the GVC736CE101 and 5SXE12-0184. It integrates intuitive diagnostic tools that provide actionable insights into system health, enabling predictive maintenance and minimizing unplanned downtime.

Robust power handling: The ABB 5SXE12-0184 features advanced IGBT chip technology that minimizes switching losses, even under high-current conditions. Its enhanced thermal management system, including a copper base plate, ensures stable operation at full load for extended periods. The module’s rugged construction resists vibration and environmental stress, making it ideal for harsh industrial environments. Together, these components offer seamless compatibility with ABB’s automation platforms, simplifying integration and operation.

Application Fields

The ABB GVC736CE101, ABB 3BHE039203R0101, and ABB 5SXE12-0184 are widely deployed across critical industrial sectors:

In renewable energy plants, the GVC736CE101 converts variable DC power from wind turbines or solar arrays into stable AC for grid integration, while the 3BHE039203R0101 monitors grid parameters to ensure compliance. The 5SXE12-0184 enhances efficiency in inverter systems, maximizing energy harvest.

In industrial drives, these components power large motor control systems for pumps, compressors, and conveyor belts in manufacturing and mining. The 5SXE12-0184 handles high-current switching, the GVC736CE101 regulates motor voltage, and the 3BHE039203R0101 synchronizes operations, reducing energy consumption by up to 25%.

They also play a key role in power distribution networks, where they manage voltage regulation and load balancing, ensuring stable power supply to critical infrastructure.

Installation and Maintenance

Installation preparation: Before installing the ABB GVC736CE101, ensure the mounting panel is rated for its weight and that input/output wiring meets medium-voltage safety standards. For the ABB 3BHE039203R0101, verify DIN rail stability and confirm communication cable shielding to prevent EMI interference. For the ABB 5SXE12-0184, check that the heat sink has adequate cooling capacity (≥200W) and apply thermal grease evenly.

Maintenance recommendations: Inspect the GVC736CE101 quarterly for dust accumulation on heatsinks and tighten terminal connections annually. For the 3BHE039203R0101, perform bi-annual firmware updates using ABB’s diagnostic software to ensure compatibility. The 5SXE12-0184 requires monthly checks for thermal stress signs, with heat sink cleaning every six months to maintain cooling efficiency. All components should undergo functional testing annually to validate performance.

Product Assurance

Hong Kong Saul Electric Co., Ltd. provides comprehensive support for the ABB GVC736CE101, ABB 3BHE039203R0101, and ABB 5SXE12-0184, backed by 17 years of expertise in industrial control components. All products come with a 1-year warranty covering manufacturing defects, ensuring reliability in critical applications. With extensive ready stock and global supply chain 优势，we guarantee prompt delivery even for hard-to-find models, meeting urgent customer needs.

Our technical team offers professional guidance on installation, configuration, and troubleshooting. For inquiries, contact us via WhatsApp or email. Hong Kong Saul Electric Co., Ltd. is your trusted partner for reliable industrial control solutions, committed to quality and customer satisfaction.
